Bonjour à tous !
Aujourd’hui un petit tuto de base pour installer Centreon 2.7 (La version que vous pouvez voir sur CES 3.3)
Cette version est (selon moi) tout simplement magnifique, vous êtes prêt ?
Alors vous venez de finir votre installation de Debian 8, vous avez votre mot de passe root en main, vous avez installer le serveur ssh (apt-get install openssh-server) et venez juste de vous connecter en ssh à votre serveur, nous allons pouvoir commencer :
Connectez-vous avec le compte root :
su
Lançons la mise à jour des packets Debian pour commencer :
apt-get update apt-get upgrade
Installation des packets de base nécessaire à la compilation :
apt-get install build-essential cmake -y
Installation de la librairie Centreon :
cd /usr/local/src wget https://s3-eu-west-1.amazonaws.com/centreon-download/public/centreon-clib/centreon-clib-1.4.2.tar.gz tar xzf centreon-clib-1.4.2.tar.gz cd centreon-clib-1.4.2/build
Préparation de la compilation :
cmake
-DWITH_TESTING=0
-DWITH_PREFIX=/usr
-DWITH_SHARED_LIB=1
-DWITH_STATIC_LIB=0
-DWITH_PKGCONFIG_DIR=/usr/lib/pkgconfig .
Vous devriez avoir comme résultat :
-- Configuration Summary -- --------------------- -- -- Project -- - Name Centreon Clib -- - Version 1.4.2 -- - With shared library Yes -- - With static library No -- -- System -- - Name Linux -- - Version 3.2.0-4-amd64 -- - Processor x86_64 -- -- Build -- - Compiler /usr/bin/c++ (GNU) -- - Extra compilation flags -- - Build unit tests No -- -- Installation -- - Prefix /usr -- - Library directory /usr/lib -- - Include directory /usr/include -- - Package None -- - pkg-config directory /usr/lib/pkgconfig -- -- Configuring done -- Generating done -- Build files have been written to: /usr/local/src/centreon-clib-1.4.2/build
Nous allons maintenant compiler la librairie :
make make install
Installation des connecteurs Perl et SSH optionnels pour Centreon (Fortement conseiller car ils améliorent la vitesse d’exécution des plugins Perl, ils ne sont utilisable qu’avec Centreeon Engine)
Installation des packets de base nécessaire à Perl Connector :
apt-get install libperl-dev -y
Installation de la librairie Perl Connector :
cd /usr/local/src wget https://s3-eu-west-1.amazonaws.com/centreon-download/public/centreon-connectors/centreon-connector-1.1.2.tar.gz tar xzf centreon-connector-1.1.2.tar.gz cd centreon-connector-1.1.2/perl/build
Préparation de la compilation :
cmake -DWITH_PREFIX=/usr -DWITH_PREFIX_BINARY=/usr/lib/centreon-connector -DWITH_CENTREON_CLIB_INCLUDE_DIR=/usr/include -DWITH_TESTING=0 .
Vous devriez avoir comme résultat :
-- Configuration Summary -- --------------------- -- -- Project -- - Name Centreon Perl Connector -- - Version 1.1.2 -- -- System -- - Name Linux -- - Version 3.16.0-4-amd64 -- - Processor x86_64 -- -- Build -- - Compiler /usr/bin/c++ (GNU) -- - Extra compilation flags -D_REENTRANT -D_GNU_SOURCE -DDEBIAN -fwrapv -fno-strict-aliasing -pipe -I/usr/local/include -D_LARGEFILE_SOURCE -D_FILE_OFFSET_BITS=64 -I/usr/lib/x86_64-linux-gnu/perl/5.20/CORE -- - Unit tests disabled -- -- Install -- - Prefix /usr -- - Binary prefix /usr/lib/centreon-connector -- - Package None -- -- Libraries -- - clib include directory /usr/include -- - clib library directory /usr/lib/libcentreon_clib.so -- Configuring done -- Generating done -- Build files have been written to: /usr/local/src/centreon-connector-1.1.2/perl/build
Nous allons maintenant compiler la librairie :
make make install
Installation des packets de base nécessaire à SSH Connector :
apt-get install libssh2-1-dev libgcrypt11-dev -y
Installation de la librairie SSH Connector :
Préparation de la compilation :
cd /usr/local/src/centreon-connector-1.1.2/ssh/build cmake -DWITH_PREFIX=/usr -DWITH_PREFIX_BINARY=/usr/lib/centreon-connector -DWITH_CENTREON_CLIB_INCLUDE_DIR=/usr/include -DWITH_TESTING=0 .
Vous devriez avoir comme résultat :
-- Configuration Summary -- --------------------- -- -- Project -- - Name Centreon SSH Connector -- - Version 1.1.2 -- - Known hosts check disabled -- -- System -- - Name Linux -- - Version 3.16.0-4-amd64 -- - Processor x86_64 -- -- Build -- - Compiler /usr/bin/c++ (GNU) -- - Extra compilation flags -- - Unit tests disabled -- -- Install -- - Prefix /usr -- - Binary prefix /usr/lib/centreon-connector -- - Package None -- -- Libraries -- - clib include directory /usr/include -- - clib library directory /usr/lib/libcentreon_clib.so -- Configuring done -- Generating done -- Build files have been written to: /usr/local/src/centreon-connector-1.1.2/ssh/build
Nous allons maintenant compiler la librairie :
make make install
Installation de Centreon Engine :
Nous allons commencer par créer l’user/group pour centreon-engine :
groupadd -g 6001 centreon-engine useradd -u 6001 -g centreon-engine -m -r -d /var/lib/centreon-engine -c "Centreon-engine Admin" -s /bin/bash centreon-engine
Installation des packets de base nécessaire à centreon-engine :
apt-get install libcgsi-gsoap-dev zlib1g-dev libssl-dev libxerces-c-dev -y
Installation de centreon-engine :
cd /usr/local/srcwget https://s3-eu-west-1.amazonaws.com/centreon-download/public/centreon-engine/centreon-engine-1.4.15.tar.gzwget https://s3-eu-west-1.amazonaws.com/centreon-download/public/centreon-engine/centreon-engine-1.5.0.tar.gztar xzf centreon-engine-1.4.15.tar.gztar xzf centreon-engine-1.5.0.tar.gzcd centreon-engine-1.4.15/build/cd centreon-engine-1.5.0/build/
Préparation de la compilation :
cmake
-DWITH_CENTREON_CLIB_INCLUDE_DIR=/usr/include
-DWITH_CENTREON_CLIB_LIBRARY_DIR=/usr/lib
-DWITH_PREFIX=/usr
-DWITH_PREFIX_BIN=/usr/sbin
-DWITH_PREFIX_CONF=/etc/centreon-engine
-DWITH_USER=centreon-engine
-DWITH_GROUP=centreon-engine
-DWITH_LOGROTATE_SCRIPT=1
-DWITH_VAR_DIR=/var/log/centreon-engine
-DWITH_RW_DIR=/var/lib/centreon-engine/rw
-DWITH_STARTUP_DIR=/etc/init.d
-DWITH_PKGCONFIG_SCRIPT=1
-DWITH_PKGCONFIG_DIR=/usr/lib/pkgconfig
-DWITH_TESTING=0
-DWITH_WEBSERVICE=1 .
Vous devriez avoir comme résultat :
-- Configuration Summary -- --------------------- -- -- Project -- - Name Centreon Engine -- - Version 1.5.0 -- -- System -- - Name Linux -- - Version 3.16.0-4-amd64 -- - Processor x86_64 -- -- Build -- - Compiler /usr/bin/c++ (GNU) -- - Extra compilation flags -- - Build static core library yes -- - External commands module enabled -- - Webservice module enabled -- - Unit tests disabled -- - pkg-config script enabled -- - logrotate script enabled -- - Startup script SysV-style script -- -- Install -- - Prefix /usr -- - Binary prefix /usr/sbin -- - Configuration prefix /etc/centreon-engine -- - Library prefix /usr/lib/centreon-engine -- - Include prefix /usr/include/centreon-engine -- - var directory /var/log/centreon-engine -- - Log archive directory /var/log/centreon-engine/archives -- - RW directory /var/lib/centreon-engine/rw -- - Lock prefix /var/lock/centengine.lock -- - pkg-config directory /usr/lib/pkgconfig -- - logrotate directory /etc/logrotate.d -- - Startup directory /etc/init.d -- - User centreon-engine -- - Group centreon-engine -- - Package None -- -- Libraries -- - clib include directory /usr/include -- - clib library directory /usr/lib/libcentreon_clib.so -- Configuring done -- Generating done -- Build files have been written to: /usr/local/src/centreon-engine-1.5.0/build
Nous allons maintenant compiler la librairie :
make make install
Vérifions maintenant que centreon-engine est correctement installé :
centengine -V
Vous devriez avoir comme résultat :
[1450348876] [9171] Centreon Engine 1.5.0 [1450348876] [9171] [1450348876] [9171] Copyright 1999-2009 Ethan Galstad [1450348876] [9171] Copyright 2009-2010 Nagios Core Development Team and Community Contributors [1450348876] [9171] Copyright 2011-2015 Merethis [1450348876] [9171] [1450348876] [9171] This program is free software: you can redistribute it and/or [1450348876] [9171] modify it under the terms of the GNU General Public License version 2 [1450348876] [9171] as published by the Free Software Foundation. [1450348876] [9171] [1450348876] [9171] Centreon Engine is distributed in the hope that it will be useful, [1450348876] [9171] but WITHOUT ANY WARRANTY; without even the implied warranty of [1450348876] [9171] MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE. See the GNU [1450348876] [9171] General Public License for more details. [1450348876] [9171] [1450348876] [9171] You should have received a copy of the GNU General Public License [1450348876] [9171] along with this program. If not, see [1450348876] [9171] <http://www.gnu.org/licenses/>.
Paramétrons centreon-engine pour qu’il démarre automatiquement :
update-rc.d centengine defaults
Installation des Plugins pour Centreon-Engine :
Installation des packets de base nécessaire aux Plugins de centreon-engine :
apt-get install libgnutls28-dev libssl-dev libkrb5-dev libldap2-dev libsnmp-dev gawk libwrap0-dev libmcrypt-dev smbclient fping gettext dnsutils libmysqlclient-dev -y
Téléchargement des Plugins Nagios :
cd /usr/local/src wget http://nagios-plugins.org/download/nagios-plugins-2.1.1.tar.gz tar -xzf nagios-plugins-2.1.1.tar.gz cd nagios-plugins-2.1.1
Installation des Plugins Nagios :
./configure --with-nagios-user=centreon-engine --with-nagios-group=centreon-engine --prefix=/usr/lib/nagios/plugins --libexecdir=/usr/lib/nagios/plugins --enable-perl-modules --with-openssl=/usr/bin/openssl make make install
Installation des Plugins pour Centreon :
Installation des packets de base nécessaire aux Plugins de Centreon :
apt-get install libxml-libxml-perl libjson-perl libwww-perl libxml-xpath-perl libnet-telnet-perl libnet-ntp-perl libnet-dns-perl libdbi-perl libdbd-mysql-perl libdbd-pg-perl -y
Installation de git nécessaire à la récupération des plugins Centreon sur leurs github :
apt-get install git-core
Récupération des Plugins Centreon sur Github :
cd /usr/local/src git clone https://github.com/centreon/centreon-plugins.git
Installation des Plugins Centreon :
cd centreon-plugins chmod +x centreon_plugins.pl cp -R * /usr/lib/nagios/plugins/
Installation de Centreon-Broker :
Nous allons commencer par créer l’user/group pour centreon-broker :
groupadd -g 6002 centreon-broker useradd -u 6002 -g centreon-broker -m -r -d /var/lib/centreon-broker -c "Centreon-broker Admin" -s /bin/bash centreon-broker
Ajout de l’user centreon-engine au groupe centreon-broker :
usermod -aG centreon-broker centreon-engine
Installation des packets de base nécessaire à Centreon-Broker :
apt-get install librrd-dev libqt4-dev libqt4-sql-mysql libgnutls28-dev lsb-release -y
Téléchargement de Centreon-Broker :
cd /usr/local/srcwget https://s3-eu-west-1.amazonaws.com/centreon-download/public/centreon-broker/centreon-broker-2.10.1.tar.gzwget https://s3-eu-west-1.amazonaws.com/centreon-download/public/centreon-broker/centreon-broker-2.11.0.tar.gztar xzf centreon-broker-2.10.1.tar.gztar xzf centreon-broker-2.11.0.tar.gzcd /usr/local/src/centreon-broker-2.10.1/build/cd centreon-broker-2.11.0/
Préparation de la compilation :
cmake
-DWITH_DAEMONS='central-broker;central-rrd'
-DWITH_GROUP=centreon-broker
-DWITH_PREFIX=/usr
-DWITH_PREFIX_BIN=/usr/sbin
-DWITH_PREFIX_CONF=/etc/centreon-broker
-DWITH_PREFIX_LIB=/usr/lib/centreon-broker
-DWITH_PREFIX_MODULES=/usr/share/centreon/lib/centreon-broker
-DWITH_STARTUP_DIR=/etc/init.d
-DWITH_STARTUP_SCRIPT=auto
-DWITH_TESTING=0
-DWITH_USER=centreon-broker .
Vous devriez avoir comme résultat :
-- Configuration Summary -- --------------------- -- -- Project -- - Name Centreon Broker -- - Version 2.11.0 -- -- System -- - Name Linux -- - Version 3.16.0-4-amd64 -- - Processor x86_64 -- -- Build -- - Compiler /usr/bin/c++ (GNU) -- - Extra compilation flags -- - Qt 4.8.6 -- - Unit tests disabled -- - Startup script sysv -- - Module stats, neb, file, compression, correlation, dumper, rrd, sql, storage, influxdb, graphite, bam, tcp, tls, bbdo, ndo -- -- Install -- - Prefix /usr -- - Binary prefix /usr/sbin -- - Library prefix /usr/lib/centreon-broker -- - Modules prefix /usr/share/centreon/lib/centreon-broker -- - Include prefix /usr/include/centreon-broker -- - Configuration prefix /etc/centreon-broker -- - Startup dir /etc/init.d -- - User centreon-broker -- - Group centreon-broker -- - Package None -- -- Configuring done -- Generating done -- Build files have been written to: /usr/local/src/centreon-broker-2.11.0/build
Nous allons maintenant compiler Centreon-Broker :
make make install
ATTENTION !! Avec la nouvelle version 2.7 de Centreon est apparu un nouveau module dumber (05-dumper.so) alors que les précédentes versions utilisaient le module stat (15-stats.so), il entre en conflit avec le nouveau module et provoque l’arrêt du processus cbd quand on va sur la page des statistiques. Nous allons donc supprimer l’ancien module stats :
rm /usr/local/centreon-broker/lib/centreon-broker/05-stats.so
Paramétrons centreon-broker pour qu’il démarre automatiquement :
update-rc.d cbd defaults
Installation de SNMP :
Installation des packets de base nécessaire pour le protocole SNMP :
apt-get install snmp snmpd snmptrapd libnet-snmp-perl libsnmp-perl -y
Paramétrage du daemon SNMP :
Nous allons éditer le fichier : /etc/snmp/snmpd.conf
nano /etc/snmp/snmpd.conf
Modifiez le fichier pour avoir :
agentAddress udp:localhost:161 rocommunity public localhost iquerySecName internalUser trapsink localhost public
Nous allons réduire la verbosité du daemon snmpd :
nano /etc/default/snmpd
Modifiez le fichier pour avoir :
# snmpd options (use syslog, close stdin/out/err). SNMPDOPTS='-LS4d -Lf /dev/null -u snmp -g snmp -I -smux,mteTrigger,mteTriggerConf -p /run/snmpd.pid'
Nous allons maintenant ajouter la réception de traps snmp :
nano /etc/default/snmptrapd
Modifiez le fichier pour avoir :
TRAPDRUN=yes # snmptrapd options (use syslog). TRAPDOPTS='-On -Lsd -p /run/snmptrapd.pid'
Installation des MIBS SNMP :
Nous allons modifier le fichier de configuration des sources de dépots debian pour ajouter les dépots « non-free »:
Nous allons éditer le fichier : /etc/apt/sources.list
nano /etc/apt/sources.list
Ajoutez à la fin du fichier :
#DEPOTS NON-FREE deb http://ftp.fr.debian.org/debian/ jessie main non-free deb-src http://ftp.fr.debian.org/debian/ jessie main non-free
Mettez à jour vos dépots :
apt-get update
Installation des MIBS :
apt-get install snmp-mibs-downloader -y
Créez un lien de vos MIBS :
ln -s /usr/share/mibs/ /usr/share/snmp/mibs
Editez le fichier : /etc/default/snmpd
nano /etc/default/snmpd
Puis modifiez le pour avoir :
export MIBDIRS=/usr/share/mibs export MIBS=ALL
Editez le fichier : /etc/snmp/snmp.conf
nano /etc/snmp/snmpd.conf
Commentez la ligne :
#mibs ALL
Redémarrons les services SNMP :
service snmpd restart service snmptrapd restart
Testons le service SNMP :
snmpwalk -c public -v 2c localhost
Si le service est correctement paramétré vous verrez toutes les OID déflier :
... NOTIFICATION-LOG-MIB::nlmLogDateAndTime."default".1 = STRING: 2015-12-16,18:0:55.0,+1:0 NOTIFICATION-LOG-MIB::nlmLogEngineID."default".1 = "" NOTIFICATION-LOG-MIB::nlmLogContextEngineID."default".1 = "" NOTIFICATION-LOG-MIB::nlmLogContextName."default".1 = STRING: NOTIFICATION-LOG-MIB::nlmLogNotificationID."default".1 = OID: SNMPv2-MIB::coldStart NOTIFICATION-LOG-MIB::nlmLogVariableID."default".1.1 = OID: DISMAN-EVENT-MIB::sysUpTimeInstance NOTIFICATION-LOG-MIB::nlmLogVariableID."default".1.2 = OID: SNMP-COMMUNITY-MIB::snmpTrapAddress.0 NOTIFICATION-LOG-MIB::nlmLogVariableID."default".1.3 = OID: SNMPv2-MIB::snmpTrapEnterprise.0 NOTIFICATION-LOG-MIB::nlmLogVariableValueType."default".1.1 = INTEGER: timeTicks(3) NOTIFICATION-LOG-MIB::nlmLogVariableValueType."default".1.2 = INTEGER: ipAddress(5) NOTIFICATION-LOG-MIB::nlmLogVariableValueType."default".1.3 = INTEGER: objectId(7) NOTIFICATION-LOG-MIB::nlmLogVariableTimeTicksVal."default".1.1 = Timeticks: (1) 0:00:00.01 NOTIFICATION-LOG-MIB::nlmLogVariableIpAddressVal."default".1.2 = IpAddress: 192.168.92.18 NOTIFICATION-LOG-MIB::nlmLogVariableOidVal."default".1.3 = OID: NET-SNMP-MIB::netSnmpAgentOIDs.10
Installation de Centreon UI :
Nous allons commencer par créer l’user/group pour Centreon UI:
groupadd -g 6000 centreon useradd -u 6000 -g centreon -m -r -d /var/lib/centreon -c "Centreon Admin" -s /bin/bash centreon
Installation des packets de base nécessaire à Centreon UI :
apt-get install sudo tofrodos bsd-mailx lsb-release mariadb-server libmysqlclient-dev apache2 apache2-mpm-prefork php5 php5-mysql php-pear php5-ldap php5-snmp php5-gd rrdtool librrds-perl libconfig-inifiles-perl libcrypt-des-perl libdigest-hmac-perl libdigest-sha-perl libgd-gd2-perl php5-sqlite -y
Téléchargement de Centreon UI :
cd /usr/local/src wget https://s3-eu-west-1.amazonaws.com/centreon-download/public/centreon/centreon-2.6.4.tar.gz tar xzf centreon-2.6.4.tar.gz cd centreon-2.6.4
Installation de Centreon UI :
./install.sh -i
Au lancement, le script vérifie que toutes les dépendances sont bien présentes :
############################################################################### # # # Centreon (www.centreon.com) # # Thanks for using Centreon # # # # v2.6.4 # # # # infos@centreon.com # # # # Make sure you have installed and configured # # sudo - sed - php - apache - rrdtool - mysql # # # ############################################################################### ------------------------------------------------------------------------ Checking all needed binaries ------------------------------------------------------------------------ rm OK cp OK mv OK /bin/chmod OK /bin/chown OK echo OK more OK mkdir OK find OK /bin/grep OK /bin/cat OK /bin/sed OK You will now read Centreon Licence. Press enter to continue.
Pressez la touche enter, ensuite la licence d’utilisateur s’affiche :
This General Public License does not permit incorporating your program into proprietary programs. If your program is a subroutine library, you may consider it more useful to permit linking proprietary applications with the library. If this is what you want to do, use the GNU Library General Public License instead of this License. Do you accept GPL license ? [y/n], default to [n]: > y
Pressez la touche y et enter. Le script d’installation va ensuite vous demander si vous souhaitez installer différents modules :
------------------------------------------------------------------------
Please choose what do you want to install
------------------------------------------------------------------------
Do you want to install Centreon Web Front
[y/n], default to [n]:
> y
Do you want to install Centreon CentCore
[y/n], default to [n]:
> y
Do you want to install Centreon Nagios Plugins
[y/n], default to [n]:
> y
Do you want to install Centreon Snmp Traps process
[y/n], default to [n]:
> y
Le script va maintenant installé les différents modules précédemment sélectionné, le script vous demande maintenant le chemin d’installation pour Centreon UI :
------------------------------------------------------------------------
Start CentWeb Installation
------------------------------------------------------------------------
Where is your Centreon directory?
default to [/usr/local/centreon]
>/usr/share/centreon
Path /usr/share/centreon OK
Le script va ensuite vous demander le répertoire contenant les logs de Centreon :
Where is your Centreon log directory default to [/usr/local/centreon/log] > /var/log/centreon Do you want me to create this directory ? [/var/log/centreon] [y/n], default to [n]: > y Path /var/log/centreon OK
Le script vous demande maintenant les différents répertoires des fichiers de configuration de Centreon :
Where is your Centreon etc directory default to [/etc/centreon] > Do you want me to create this directory ? [/etc/centreon] [y/n], default to [n]: > y Path /etc/centreon OK Where is your Centreon binaries directory default to [/usr/local/centreon/bin] > /usr/share/centreon/bin Do you want me to create this directory ? [/usr/share/centreon/bin] [y/n], default to [n]: > y Path /usr/share/centreon/bin OK Where is your Centreon data informations directory default to [/usr/local/centreon/data] > /usr/share/centreon/data Do you want me to create this directory ? [/usr/share/centreon/data] [y/n], default to [n]: > y Path /usr/share/centreon/data OK Where is your Centreon variable library directory? default to [/var/lib/centreon] > Do you want me to create this directory ? [/var/lib/centreon] [y/n], default to [n]: > y Path /var/lib/centreon OK /usr/bin/rrdtool OK /usr/bin/mail OK /usr/bin/php OK Where is PEAR [PEAR.php] default to [/usr/share/php/PEAR.php] > Path /usr/share/php OK /usr/bin/perl OK Finding Apache user : www-data Finding Apache group : www-data
Le script demande quel user/group utiliser :
What is the Centreon group ? [centreon] default to [centreon] > What is the Centreon user ? [centreon] default to [centreon] >
Nous allons ensuite dire au script d’utiliser centreon-engine et centreon-broker ainsi que le chemin ou se trouve les Plugins :
What is the Monitoring engine user ? > centreon-engine What is the Broker user ? (optional) > centreon-broker What is the Monitoring engine log directory ? > /var/log/centreon-engine Where is your monitoring plugins (libexec) directory ? default to [/usr/lib/nagios/plugins] > Path /usr/lib/nagios/plugins OK Add group centreon to user www-data OK Add group centreon to user centreon-engine OK Add group centreon-engine to user www-data OK Add group centreon-engine to user centreon OK
Le script vous demande le chemin du fichier de configuration de sudo ainsi que les chemins des différents modules :
------------------------------------------------------------------------ Configure Sudo ------------------------------------------------------------------------ Where is sudo configuration file default to [/etc/sudoers] > /etc/sudoers OK What is the Monitoring engine init.d script ? > /etc/init.d/centengine What is the Monitoring engine binary ? > /usr/sbin/centengine What is the Monitoring engine configuration directory ? > /etc/centreon-engine Where is the configuration directory for broker module ? > /etc/centreon-broker Where is the init script for broker module daemon ? > /etc/init.d/cbd Your sudo is not configured Do you want me to configure your sudo ? (WARNING) [y/n], default to [n]: > y Configuring Sudo OK
Le script va ensuite configurer le serveur web Apache :
------------------------------------------------------------------------ Configure Apache server ------------------------------------------------------------------------ Do you want to add Centreon Apache sub configuration file ? [y/n], default to [n]: > y Create '/etc/apache2/conf.d/centreon.conf' OK Configuring Apache OK Do you want to reload your Apache ? [y/n], default to [n]: > y Reloading Apache service OK Preparing Centreon temporary files Change right on /var/log/centreon OK Change right on /etc/centreon OK Change macros for insertBaseConf.sql OK Change macros for sql update files OK Change macros for php files OK Change macros for perl binary OK Change right on /etc/centreon-engine OK Add group centreon-broker to user www-data OK Add group centreon-broker to user centreon-engine OK Add group centreon to user centreon-broker OK Change right on /etc/centreon-broker OK Copy CentWeb in system directory Install CentWeb (web front of centreon) OK Change right for install directory Change right for install directory OK Install libraries OK Write right to Smarty Cache OK Copying libinstall OK Change macros for centreon.cron OK Install Centreon cron.d file OK Change macros for centAcl.php OK Change macros for downtimeManager.php OK Install cron directory OK Change right for eventReportBuilder OK Change right for dashboardBuilder OK Change macros for centreon.logrotate OK Install Centreon logrotate.d file OK Prepare centFillTrapDB OK Install centFillTrapDB OK Prepare centreon_trap_send OK Install centreon_trap_send OK Prepare centreon_check_perfdata OK Install centreon_check_perfdata OK Prepare centreonSyncPlugins OK Install centreonSyncPlugins OK Prepare centreonSyncArchives OK Install centreonSyncArchives OK Install generateSqlLite OK Install changeRrdDsName.pl OK Prepare export-mysql-indexes OK Install export-mysql-indexes OK Prepare import-mysql-indexes OK Install import-mysql-indexes OK Centreon Web Perl lib installed OK ------------------------------------------------------------------------ Pear Modules ------------------------------------------------------------------------ Check PEAR modules PEAR 1.4.9 1.9.5 OK DB 1.7.6 NOK DB_DataObject 1.8.4 NOK DB_DataObject_FormBuilder 1.0.0RC4 NOK MDB2 2.0.0 NOK Date 1.4.6 NOK Archive_Tar 1.1 1.3.12 OK Auth_SASL 1.0.1 NOK Console_Getopt 1.2 1.3.1 OK Net_SMTP 1.2.8 NOK Net_Socket 1.0.1 NOK Net_Traceroute 0.21 NOK Net_Ping 2.4.1 NOK Validate 0.6.2 NOK XML_RPC 1.4.5 NOK SOAP 0.10.1 NOK Log 1.9.11 NOK Archive_Zip 0.1.2 NOK Do you want me to install/upgrade your PEAR modules [y/n], default to [y]: > y
Le script va ensuite mettre à jour vos modules PEAR,
Upgrading PEAR modules Installing PEAR modules DB 1.7.6 1.8.2 OK DB_DataObject 1.8.4 1.11.4 OK DB_DataObject_FormBuilder 1.0.0RC4 1.0.2 OK MDB2 2.0.0 2.4.1 OK Auth_SASL 1.0.1 1.0.6 OK Net_SMTP 1.2.8 1.6.2 OK Net_Traceroute 0.21 0.21.3 OK Net_Ping 2.4.1 2.4.5 OK Validate 0.6.2 0.8.5 OK XML_RPC 1.4.5 1.5.5 OK SOAP 0.10.1 0.13.0 OK Log 1.9.11 1.12.8 OK Archive_Zip 0.1.2 0.1.2 OK Check PEAR modules PEAR 1.4.9 1.9.5 OK DB 1.7.6 1.8.2 OK DB_DataObject 1.8.4 1.11.4 OK DB_DataObject_FormBuilder 1.0.0RC4 1.0.2 OK MDB2 2.0.0 2.4.1 OK Date 1.4.6 1.4.7 OK Archive_Tar 1.1 1.3.12 OK Auth_SASL 1.0.1 1.0.6 OK Console_Getopt 1.2 1.3.1 OK Net_SMTP 1.2.8 1.6.2 OK Net_Socket 1.0.1 1.0.14 OK Net_Traceroute 0.21 0.21.3 OK Net_Ping 2.4.1 2.4.5 OK Validate 0.6.2 0.8.5 OK XML_RPC 1.4.5 1.5.5 OK SOAP 0.10.1 0.13.0 OK Log 1.9.11 1.12.8 OK Archive_Zip 0.1.2 0.1.2 OK All PEAR modules OK ------------------------------------------------------------------------ Centreon Post Install ------------------------------------------------------------------------ Create /usr/local/centreon/www/install/install.conf.php OK Create /etc/centreon/instCentWeb.conf OK
ATTENTION !!! Si vous avez l’erreur :
XML_RPC 1.4.5 NOK
Rien de bien grave cela veut dire que le programme d’update de PEAR contient toujours le lien cassé pour XML_RPC.
Nous allons donc le mettre à jour manuellement :
Ouvrez un nouveau terminal ssh vers votre serveur Debian et lancez la commande :
pear install XML_RPC
Vous devriez avoir l’erreur suivante :
WARNING: "pear/XML_RPC" is deprecated in favor of "pear/XML_RPC2" Could not download from "https://de.pear.php.net/get/XML_RPC-1.5.5.tgz", cannot download "pear/XML_RPC" (Connection to `de.pear.php.net:443' failed: ) Error: cannot download "pear/XML_RPC" Download failed install failed
Nous allons donc télécharger le fichier manuellement :
mkdir /usr/local/src/pear wget http://download.pear.php.net/package/XML_RPC-1.5.5.tgz pear install XML_RPC-1.5.5.tgz
Vous devriez avoir le message :
install ok: channel://pear.php.net/XML_RPC-1.5.5
Vous pouvez ensuite continuer l’installation en revenant sur votre premier terminal.
Une fois vos modules PEAR à jour, le script d’installation va s’occuper de CentStorage :
------------------------------------------------------------------------ Start CentStorage Installation ------------------------------------------------------------------------ Where is your Centreon Run Dir directory? default to [/var/run/centreon] > Do you want me to create this directory ? [/var/run/centreon] [y/n], default to [n]: > y Path /var/run/centreon OK Where is your CentStorage binary directory default to [/usr/share/centreon/bin] > Path /usr/share/centreon/bin OK Where is your CentStorage RRD directory default to [/var/lib/centreon] > Path /var/lib/centreon OK Preparing Centreon temporary files /tmp/centreon-setup exists, it will be moved... install www/install/createTablesCentstorage.sql OK Creating Centreon Directory '/var/lib/centreon/status' OK Creating Centreon Directory '/var/lib/centreon/metrics' OK Install CentStorage binary OK Change right : /var/run/centreon OK Change macros for centstorage init script OK Replace Centstorage default script Macro OK Do you want me to install CentStorage init script ? [y/n], default to [n]: > n CentStorage init script not installed, please use : /usr/share/centreon/INSTALL_DIR_CENTREONexamples/centstoraPASSEDt.d Install logAnalyser OK Install logAnalyserBroker OK Install nagiosPerfTrace OK Change macros for centstorage.cron OK Install CentStorage cron OK Change macros for centstorage.logrotate OK Install Centreon Storage logrotate.d file OK Create /etc/centreon/instCentStorage.conf OK
Installation du module CentCore :
------------------------------------------------------------------------ Start CentCore Installation ------------------------------------------------------------------------ Where is your CentCore binary directory default to [/usr/share/centreon/bin] > Path /usr/share/centreon/bin OK Preparing Centreon temporary files /tmp/centreon-setup exists, it will be moved... Copy CentCore in binary directory OK Change right : /var/run/centreon OK Change right : /var/lib/centreon OK Change macros for centcore.logrotate OK Install Centreon Core logrotate.d file OK Replace CentCore init script Macro OK Replace CentCore default script Macro OK Do you want me to install CentCore init script ? [y/n], default to [n]: > y CentCore init script installed OK CentCore default script installed OK Do you want me to install CentCore run level ? [y/n], default to [n]: > y update-rc.d: using dependency based boot sequencing CentCore Perl lib installed OK Create /etc/centreon/instCentCore.conf OK
Installation des plugins pour les traps SNMP :
------------------------------------------------------------------------ Start CentPlugins Installation ------------------------------------------------------------------------ Where is your CentPlugins lib directory default to [/var/lib/centreon/centplugins] > Do you want me to create this directory ? [/var/lib/centreon/centplugins] [y/n], default to [n]: > y Path /var/lib/centreon/centplugins OK Preparing Centreon temporary files /tmp/centreon-setup exists, it will be moved... Change macros for CentPlugins OK Installing the plugins OK Change right on centreon.conf OK CentPlugins is installed ------------------------------------------------------------------------ Start CentPlugins Traps Installation ------------------------------------------------------------------------ Where is your SNMP configuration directory default to [/etc/snmp] > /etc/snmp OK Where is your CentreonTrapd binaries directory default to [/usr/local/centreon/bin] > /usr/share/centreon/bin/ /usr/share/centreon/bin/ OK Finding Apache user : www-data Preparing Centreon temporary files /tmp/centreon-setup exists, it will be moved... Change macros for snmptrapd.conf OK Replace CentreonTrapd init script Macro OK Replace CentreonTrapd default script Macro OK Do you want me to install CentreonTrapd init script ? [y/n], default to [n]: > y CentreonTrapd init script installed OK CentreonTrapd default script installed OK Do you want me to install CentreonTrapd run level ? [y/n], default to [n]: > y update-rc.d: using dependency based boot sequencing trapd Perl lib installed OK Install : snmptrapd.conf OK Install : centreontrapdforward OK Install : centreontrapd OK Create /etc/centreon/instCentPlugins.conf OK ############################################################################### # # # Go to the URL : http://debian7.localmac/centreon/ # # to finish the setup # # # # Report bugs at http://forge.centreon.com # # # # Thanks for using Centreon. # # ----------------------- # # Contact : infos@centreon.com # # http://www.centreon.com # # # ###############################################################################
Activez le site web Centreon et relancez Apache :
a2enconf centreon.conf service apache2 reload
Création des dossier pour Centreon Broker :
mkdir /var/log/centreon-broker chown centreon-broker:centreon-broker /var/log/centreon-broker chmod 775 /var/log/centreon-broker chmod 775 /var/lib/centreon-broker
Finalisation de l’installation via l’interface WEB :
Ouvrez votre navigateur et allez à l’url :
http://VotreIpCentreon/centreon/
Cliquez sur Next
Validation des dépendances, cliquez sur Next
Choisissez centreon-engine comme moteur de supervision et parametrez les chemins suivants :
Centreon Engine directory: /usr/sbin/ Centreon Engine Stats binary: /usr/sbin/centenginestats Centreon Engine var lib directory: /var/lib/centreon-engine Centreon Engine Connector path: /usr/lib/centreon-connector Centreon Engine Library (*.so) directory: /usr/lib/centreon-engine/
Choisissez centreon-broker comme broker et paramétrez les chemins suivants :
Centreon Broker etc directory: /etc/centreon-broker Centreon Broker module (cbmod.so): /usr/lib/centreon-broker/cbmod.so Centreon Broker log directory: /var/log/centreon-broker Retention file directory: /var/lib/centreon-broker Centreon Broker lib (*.so) directory: /usr/share/centreon/lib/centreon-broker
Création du compte admin
Paramétrage de la BDD
Installation et paramétrage de Centreon
Vous etes maintenant prêt à ajouter vos équipements à monitorer !
Bon courage pour la suite ;)
